The Belgian CE+T T2S ETH is the master supervisory controller for CE+T TSI modular inverter systems, featuring dual Ethernet ports, an embedded Web server, SNMP/Modbus DCIM telemetry, and real-time power analytics.
Need to confirm a model, specification, or project configuration? Our team can follow up by email or phone.
The Belgian CE+T T2S ETH is the master supervisory controller for CE+T TSI modular inverter systems, featuring dual Ethernet ports, an embedded Web server, SNMP/Modbus DCIM telemetry, and real-time power analytics.
Resolves severe power grid instability, excessive OPEX energy dissipation, battery degradation, and cabinet thermal constraints.
5G cellular cell sites, core telecom DC plants, data center critical power infrastructure, railway signaling, and industrial UPS.
| Key specifications | Value |
|---|---|
| Compatible Inverter Subracks | CE+T TSI Inverter Subrack Families |
| Network Interfaces | 10/100M Ethernet RJ45 + RS485 + Relays |
| Supported Management Protocols | HTTP/Web, SNMP v1/v2c/v3, Modbus-TCP |
| Operating Input Voltage | Wide DC Range (40V - 75V DC) |
| Non-Volatile Event Logging | 2000 Timestamped Alarm Records |
| Chassis Form Factor | 19-Inch Rackmount |
| Overall System Efficiency | Up to 96.2% (Gold Standard) |
| Acoustic Noise | ≤ 55 dBA (at 25°C ambient load) |
| Ingress Protection Rating | IP20 (Indoor Dust & Finger Proof) |
| Dielectric Withstand Voltage | 3000VAC Input to Ground (< 5mA) |
