RICEWIND Eltek Flatpack2 48/3000 HE Solar MPPT Converter (241115.805 3000W 96.5% High Power)
RICEWIND Eltek Flatpack2 48/3000 HE Solar MPPT Converter (241115.805 3000W 96.5% High Power)
EltekModel: Flatpack2 48/3000 Solar (241115.815)
Eltek Flatpack2 48/3000 Solar MPPT Charger Converter Module (241115.815 -48V 60A 3000W MPPT)
Eltek Flatpack2 48/3000 Solar (Part Number: 241115.815) is an ultra-high efficiency MPPT solar charger converter module, stepping down 100~430VDC solar PV input to regulated -48VDC telecom power.
Talk to RICEWIND
Need to confirm a model, specification, or project configuration? Our team can follow up by email or phone.
Clear support from selection to delivery
360°Technical support
N+Service commitment
3Steps shipping
100%Customer satisfaction
- PV DC Input Voltage Range
- 100VDC ~ 430VDC (MPPT 150~400VDC)
- Nominal DC Output Voltage
- -48VDC Nominal (-43.5VDC ~ -57.6VDC Adjustable)
- Maximum Output Current
- 62.5A Max DC Output
- Rated Output Power
- 3000W MPPT Rated Capacity
- Peak Conversion Efficiency
- ≥96.5% Peak PV Efficiency
- Form Factor & Mounting
- Flatpack2 1U Hot-Plug Modular Cassette
What this product is
What this product is
A hot-pluggable solar DC/DC power conversion module sharing standard Flatpack2 power subracks.
What problem it solves
Delivers green off-grid solar energy to remote cellular towers, slashing diesel generator fuel consumption and maintenance costs.
Who and where it is for
Off-grid cellular towers, hybrid green power sites, remote microgrids, and solar energy storage systems.
Core advantages
- High-precision MPPT algorithm maximizing energy yield under all sunlight conditions
- Industry-leading ≥96.5% peak conversion efficiency minimizing heat dissipation
- Wide 100VDC to 430VDC solar string input operating range
- Seamlessly co-located with AC rectifiers in standard Flatpack2 1U subracks
Technical specifications
| Key specifications | Value |
|---|---|
| PV DC Input Voltage Range | 100VDC ~ 430VDC (MPPT 150~400VDC) |
| Nominal DC Output Voltage | -48VDC Nominal (-43.5VDC ~ -57.6VDC Adjustable) |
| Maximum Output Current | 62.5A Max DC Output |
| Rated Output Power | 3000W MPPT Rated Capacity |
| Peak Conversion Efficiency | ≥96.5% Peak PV Efficiency |
| Form Factor & Mounting | Flatpack2 1U Hot-Plug Modular Cassette |
Applications
01
Solar/Diesel/Grid hybrid telecom power stations
02
Off-grid rural 4G/5G radio base station power systems
03
Outdoor green energy storage and telecom cabinets
04
Carbon-neutral telecom site energy upgrades in high-insolation regions
