The Heda EPW30-48 is an industrial carrier-grade switch-mode power rectifier module engineered for telecom central offices and cellular base station DC power plants, delivering a nominal -48V DC output (adjustable from 42V to 58V DC) with a maximum load current of 30A and a rated continuous power output of 1600W.
Need to confirm a model, specification, or project configuration? Our team can follow up by email or phone.
The EPW30-48 employs a high-frequency pulse-width modulated (PWM) dual-stage topology combining active power factor correction (APFC) with an isolated DC-DC resonant converter to deliver low-ripple telecom-quality -48V DC power. It integrates hardware-driven AC under/over-voltage shutdown, output over-voltage crowbar latching, output current limiting, thermal foldback, and localized telemetry interfaces compliant with global telecom and EMC standards.
Eliminates premature component burnout and brownout shutdowns in remote or unstable grid regions prone to severe voltage sags and transient surges; mitigates thermal runaway and current hogging in parallel redundant arrays; and eliminates downtime during maintenance via live hot-plug capability.
Cellular base stations (BBU/RRU/macro sites), optical access network nodes (FTTx/OLT), microwave repeater terminals, utility substation automation SCADA racks, and industrial 48V DC uninterruptible power supply (UPS) enclosures.
| Key specifications | Value |
|---|---|
| Rated Output Voltage | -48VDC (-42V ~ -58V) |
| Maximum Output Current | 30A |
| Rated Output Power | 1600W |
| AC Input Voltage | 90V AC ~ 290V AC |
| Maximum Efficiency | ≥ 92.0% |
| Operating Temperature Range | -40°C ~ +75°C |
| Cooling System | Forced Air Cooling with Intelligent Speed Fan |
| Hot-Swappable Support | Yes (Live Hot-Pluggable / Plug-and-Play without Power Interruption) |
