The Vertiv Liebert CRV4 is a row-based precision cooling solution designed for high-density data center environments, utilizing 380V 3-phase AC input, a DC inverter brushless scroll compressor, and premium EC centrifugal fans to deliver horizontal airflow directly neutralizing cabinet hot spots with an SHF exceeding 0.95.
Need to confirm a model, specification, or project configuration? Our team can follow up by email or phone.
CRV4 is an advanced in-row precision cooling module with 300mm/600mm widths, deployed between standard IT racks in cold/hot aisle containment setups. It integrates inverter compressors, electronic expansion valves, backward-curved EC fans, and the iCOM intelligent control platform.
Eliminates high-density cabinet hotspots and air recirculation issues without the airflow inefficiencies of raised-floor downflow units, preventing short-cycling and driving down the power usage effectiveness (PUE) of mission-critical compute rows.
Enterprise and hyperscale cloud data centers, modular aisle containment solutions, edge computing edge facilities, and critical telecommunication switching centers.
| Key specifications | Value |
|---|---|
| Rated Cooling Capacity | 25kW ~ 45kW In-Row Precision Cooling Capacity |
| Sensible Heat Ratio (SHF) | ≥ 0.95 |
| Airflow Delivery & Fan Type | Horizontal In-Row Airflow (Eliminates Server Hotspots) |
| Grid Power Supply System | 380V AC 50Hz (Three-Phase Five-Wire) |
| Supply Fan Type | EC High-Efficiency Backward-Curved Centrifugal Fan |
| Refrigerant Type | R410A Eco-Friendly Green Refrigerant |
| Compressor Type | Variable Speed DC Inverter Brushless Scroll Compressor |
| Control System & HMI | iCOM Intelligent Touchscreen Group Controller |
