Q: Does the Liebert EXS 60kVA support parallel clustering, and how does it manage battery bus configuration and load sharing?

The Liebert EXS 60kVA supports direct paralleling of up to 4 units for N+X redundancy or capacity scaling up to 240kVA/240kW using a redundant ring parallel bus, achieving load sharing imbalance under 3%. The DC bus offers flexible battery cell configuration ranging from 30 to 44 blocks of 12V VRLA (default 36/40 blocks) and supports modern Lithium-ion BMS integration. It features an integrated Battery Circuit Breaker (BCB), programmable temperature compensation charging, and automated battery impedance/self-test routines to mitigate the risk of single-cell degradation cascading into DC bus collapse.

Q: What reliability designs enable the EXS 60kVA to withstand harsh industrial, high-temperature, and remote edge telecom environments?

The EXS 60kVA features a compact floor-standing form factor (footprint ~0.35–0.6 m²) with full front-access serviceability. Critical internal PCBA assemblies are treated with industrial-grade conformal coating against dust, humidity, and chemical contaminants. It delivers continuous full-load operation from 0°C to 40°C (with derated output operation sustained up to 50°C). Thermally, it employs an isolated airflow channel isolating sensitive DSP controls from the high-temperature IGBT power stage. Integrated with IEC/EN 62040-2 Category C3 EMC filters and robust surge protection, it resists harsh grid transients and electromagnetic interference.

Question 1

What are the core electrical specifications and power efficiency metrics of the Vertiv Liebert EXS 60kVA (SKU: VERTIV-UPS-EXS-60KVA)?

Accepted Answer

The Vertiv Liebert EXS 60kVA leverages an advanced three-level online double-conversion topology, delivering 60kVA / 60kW with a true Unity Power Factor (PF 1.0, kVA=kW without derating). It supports an ultra-wide three-phase input window of 228 to 477 VAC with input PF >0.99 and THDi <3%. In double-conversion mode (VFI), conversion efficiency reaches up to 96.2% (exceeding 99% in ECO mode). Output voltage is selectable among 380/400/415 VAC. Inverter overload tolerance supports 110% for 60 mins, 125% for 10 mins, and 150% for 1 min, ensuring continuous mission-critical protection against transient inrush currents in enterprise server rooms and edge telecom hubs.

Question 2

Does the Liebert EXS 60kVA support parallel clustering, and how does it manage battery bus configuration and load sharing?

Accepted Answer

The Liebert EXS 60kVA supports direct paralleling of up to 4 units for N+X redundancy or capacity scaling up to 240kVA/240kW using a redundant ring parallel bus, achieving load sharing imbalance under 3%. The DC bus offers flexible battery cell configuration ranging from 30 to 44 blocks of 12V VRLA (default 36/40 blocks) and supports modern Lithium-ion BMS integration. It features an integrated Battery Circuit Breaker (BCB), programmable temperature compensation charging, and automated battery impedance/self-test routines to mitigate the risk of single-cell degradation cascading into DC bus collapse.

Question 3

What reliability designs enable the EXS 60kVA to withstand harsh industrial, high-temperature, and remote edge telecom environments?

Accepted Answer

The EXS 60kVA features a compact floor-standing form factor (footprint ~0.35–0.6 m²) with full front-access serviceability. Critical internal PCBA assemblies are treated with industrial-grade conformal coating against dust, humidity, and chemical contaminants. It delivers continuous full-load operation from 0°C to 40°C (with derated output operation sustained up to 50°C). Thermally, it employs an isolated airflow channel isolating sensitive DSP controls from the high-temperature IGBT power stage. Integrated with IEC/EN 62040-2 Category C3 EMC filters and robust surge protection, it resists harsh grid transients and electromagnetic interference.

Key specifications	Value
Apparent Power	60000 VA
Active Power	60000 W
Output Power Factor PF	1.0
Topology	Highly reliable integrated industrial-grade online double-conversion UPS
AC Input Voltage	228 ~ 477 VAC (three-phase input)
DC Output Voltage	380/400/415 VAC
Power Conversion Efficiency	96.2%
Form Factor	Integrated Floor-Standing Monolithic UPS Cabinet
Physical Dimensions	1600 × 600 × 850 mm
Operating Temperature Range	0°C to +40°C

Vertiv Liebert EXS 60kVA Monolithic Online Double-Conversion UPS (60kVA/60kW PF 1.0)

Talk to RICEWIND

What this product is

What this product is

What problem it solves

Who and where it is for

Core advantages

Technical specifications

Applications

Enterprise and cloud data center core networking suites, server clusters, and SAN storage arrays

Financial banking transactions, securities clearing systems, and trading floor mission-critical IT

Healthcare medical imaging suites (MRI, CT scanners) and critical intensive care instrumentation

Industrial automation production lines, robotic workcells, and supervisory PLC control systems
