Question 1

How does the 600W compact door-mounted AC ensure structural compatibility and telemetry integration in outdoor enclosures?

Accepted Answer

Featuring an ultra-compact door/side-mount mechanical form factor, the ENCLOSURE-AC-600W utilizes standardized flange cutout dimensions compatible with mainstream micro-BTS, outdoor BBU, and edge battery/power cabinets. For integration, it is equipped with dry contact alarm outputs for high temperature and compressor fault monitoring, with optional RS485 (Modbus-RTU) expansion for seamless integration into local Field Supervision Units (FSU) and centralized OSS/EMS, enabling remote temperature setpoint adjustments, power telemetry, and status polling.

Question 2

How does the ENCLOSURE-AC-600W maintain airtight reliability and thermal stability under extreme ambient conditions from -20°C to +55°C?

Accepted Answer

The unit employs a dual-loop isolated aerodynamic architecture: the internal cycle features an IP55 ingress protection rating to completely seal the cabinet from ambient moisture, dust, and corrosive airborne contaminants, while the external cycle maintains IP34 protection with hydrophilic aluminum fins and anti-corrosion coating. Rated for harsh operating temperatures from -20°C to +55°C, the system integrates compressor soft-start, thermal discharge protection, and an autonomous condensate management circuit, ensuring carrier-grade reliability with an MTBF exceeding 100,000 operating hours.

Question 3

What are the interface definitions, wiring specifications, and communication networking for the Cabinet AC 600W (SKU: ENCLOSURE-AC-600W) in temperature control and monitoring systems?

Accepted Answer

According to the official system manual, the Cabinet with Cooling System (CCS) collaborates with the Integrated Controller and Converter (ICC) and monitoring units (e.g., CPMU01/SCC800-C1): 1. Power Supply Interfaces: The cabinet infrastructure supports AC Input (AC) with three-phase four-wire, dual-live wire, or single-phase configurations, as well as DC Input (DC) connected to Energy Storage Subsystems (ESS) such as ESM-48100/ESM-48150 lithium batteries. 2. Sensor and Communication Pinouts: Supports connections for digital temperature and humidity sensors, smoke sensors, water sensors, communication extension modules (NIM01C3), and signal surge protectors (SPM01A). 3. Networking and Autonomous Operation: The ICC monitoring unit handles logic scheduling and status reporting to the NetEco Operations Support System (OSS). In offline or maintenance scenarios, hot-swap/replacement of the monitoring unit is supported without disconnecting AC input or DC output (keeping loads powered), ensuring continuous thermal protection and system stability.

Key specifications	Value
Rated Cooling Capacity	600 W
Grid Power Supply System	380V 3-Phase / 220V 1-Phase Compatible V AC
Rated Input Power	280 W
Max Operating Current	1.6 A
Refrigerant Type	R134a Eco Refrigerant
Ingress Protection (IP Rating)	Internal Loop IP55 / External Loop IP34 (Sealed Dust & Water Proof)
Internal Airflow Volume	150 m³/h
Operating Temperature Range	-20 ~ +55°C
Operating Noise Level	≤ 55 dB(A)
Physical Dimensions	580 × 310 × 170 mm
Net Weight	16.5 kg
Installation / Mounting Mode	Outdoor Cabinet External (Door-Mounted / Side Wall-Mounted)
Communication Interface	RS485 (Standard Modbus-RTU) + Dry Contact Alarm

Compact Outdoor Telecom Cabinet Industrial Air Conditioner AC 600W (Compact Outdoor Side/Door Mount IP55)

Talk to RICEWIND

What this product is

What this product is

What problem it solves

Who and where it is for

Core advantages

Technical specifications

Applications

Hyperscale and enterprise cloud data center high-density server halls and aisle containment

Telecommunications switching centers, optical transmission rooms, and carrier core facilities

High-reliability industrial test laboratories and clean room production environments

Rail transit command signaling centers and electrical power grid dispatch operations

Frequently asked questions
