Eltek 252189 Subrack Telecom DC Power System (-48V 4-Slot Flatpack2)
Compact 2U -48VDC telecom-grade embedded power system supporting high-efficiency Flatpack2 rectifiers with integrated distribution and intelligent battery management.
EltekModel: Eltek Flatpack2 48/2000 HE (241115.100)
Eltek Flatpack2 48/2000 HE Rectifier Module (241115.100)
Industry-standard 48V 2000W telecom rectifier delivering 96.5% high efficiency, wide AC input range, and intelligent CAN bus current sharing.
Talk to RICEWIND
Need to confirm a model, specification, or project configuration? Our team can follow up by email or phone.
Clear support from selection to delivery
360°Technical support
N+Service commitment
3Steps shipping
100%Customer satisfaction
- AC Input Voltage
- 85V to 300V AC (rated 185V to 275V AC)
- DC Output Voltage
- -48VDC (-42V ~ -58V)
- Rated Output Power
- 2000W (maximum output current 41.7A @ 48V)
- Power Conversion Efficiency
- ≥ 96.5%
- Communication & Current Sharing
- Internal digital CAN bus auto load sharing (<5%)
- Official Part Number
- 241115.100 (Official global Eltek part number)
What this product is
What this product is
Industry-standard 48V 2000W telecom rectifier delivering 96.5% high efficiency, wide AC input range, and intelligent CAN bus current sharing.
What problem it solves
The Eltek Flatpack2 48/2000 HE (PN: 241115.100) is a hallmark of telecom power engineering. Boasting over 96.5% power conversion efficiency, hot-pluggable architecture, and digital CAN bus control, it drastically reduces operational power loss in data and telecom rooms.
Who and where it is for
Industry-standard 48V 2000W telecom rectifier delivering 96.5% high efficiency, wide AC input range, and intelligent CAN bus current sharing.
Core advantages
- Heavy-duty industrial construction engineered for demanding environments
- High power efficiency topology reducing heat dissipation and operational costs
- Full digital communication integration for centralized monitoring and telemetry
- Comprehensive multi-stage protection against overvoltage, overcurrent, and surges
- Compact modular footprint maximizing equipment density and site utilization
- Carrier-grade durability certified for high Mean Time Between Failures (MTBF)
Technical specifications
| Key specifications | Value |
|---|---|
| AC Input Voltage | 85V to 300V AC (rated 185V to 275V AC) |
| DC Output Voltage | -48VDC (-42V ~ -58V) |
| Rated Output Power | 2000W (maximum output current 41.7A @ 48V) |
| Power Conversion Efficiency | ≥ 96.5% |
| Communication & Current Sharing | Internal digital CAN bus auto load sharing (<5%) |
| Official Part Number | 241115.100 (Official global Eltek part number) |
| Overall System Efficiency | Up to 96.2% (Gold Standard) |
| Ingress Protection Rating | IP20 (Indoor Dust & Finger Proof) |
| Acoustic Noise | ≤ 55 dBA (at 25°C ambient load) |
| Dielectric Withstand Voltage | 3000VAC Input to Ground (< 5mA) |
Applications
01
Cellular 4G/5G macro sites and distributed antenna coverage networks
02
Mission-critical data center server rooms and edge computing facilities
03
Telecom exchange DC power plant and backup distribution systems
04
Remote industrial telemetry in energy, mining, and railway corridors
