EltekModel: Flatpack2 24/2000 HE (241115.205)
Eltek Flatpack2 24/2000 HE High Efficiency Rectifier Module (241115.205)
The Eltek Flatpack2 24/2000 HE (241115.205) is a carrier-grade 24VDC, 2000W switch-mode power supply designed for mission-critical telecom and industrial installations.
Talk to RICEWIND
Need to confirm a model, specification, or project configuration? Our team can follow up by email or phone.
Clear support from selection to delivery
360°Technical support
N+Service commitment
3Steps shipping
100%Customer satisfaction
- Nominal DC Output Voltage
- -48VDC (-42V ~ -58V)
- Rated Output Power Capacity
- 2000W (83.3A @ 24VDC)
- AC Input Voltage
- 85VAC ~ 300VAC
- Operating Efficiency Rating
- ≥95.5%
- Operating Temperature Range
- -40°C ~ +75°C
- Cooling System
- Temperature-Controlled Front-to-Rear Air Cooling
What this product is
What this product is
A compact 1U hot-pluggable AC-to-DC power conversion cassette incorporating patented soft-switching resonant bridge topologies, communicating digitally via an integrated CAN interface with Smartpack controllers.
What problem it solves
Eliminates excessive thermal dissipation and high operational cooling overheads while maintaining uninterrupted DC power across unstable utility grids prone to deep sags and extreme voltage surges.
Who and where it is for
Wireless base stations, broadband telecom access nodes, offshore platforms, railway signaling, and industrial control systems requiring redundant 24VDC rails.
Core advantages
- Utilizes a fully digital DSP topology and soft-switching resonant architecture, achieving up to 95.5% efficiency to significantly minimize thermal dissipation.
- Supports an ultra-wide AC input range of 85-300VAC, maintaining a stable 2000W full-load output under unstable grids and harsh EMC conditions.
- Features a 1U compact hot-swappable design combined with autonomous active current sharing for zero-downtime scalability and effortless maintenance.
- Engineered for extreme environments with an operating temperature of -40°C to +75°C and intelligent front-to-back forced air cooling.
Technical specifications
| Key specifications | Value |
|---|---|
| Cooling System | Temperature-Controlled Front-to-Rear Air Cooling |
| Rated Output Power Capacity | 2000W (83.3A @ 24VDC) |
| AC Input Voltage | 85VAC ~ 300VAC |
| Operating Efficiency Rating | ≥95.5% |
| Operating Temperature Range | -40°C ~ +75°C |
| Nominal DC Output Voltage | -48VDC (-42V ~ -58V) |
| Overall System Efficiency | Up to 96.2% (Gold Standard) |
| Acoustic Noise | ≤ 55 dBA (at 25°C ambient load) |
| Ingress Protection Rating | IP20 (Indoor Dust & Finger Proof) |
| Dielectric Withstand Voltage | 3000VAC Input to Ground (< 5mA) |
Applications
01
Telecom 4G/5G macro cellular base stations and distributed remote power sites
02
Enterprise-grade cloud data center mission-critical -48V DC power distribution lineups
03
Utility power grid dispatch centers and high-voltage substation DC switchgear rooms
04
Railway transit signaling, automated train control, and communications equipment rooms
