HuaweiModel: SMU11C
Huawei SMU11C Advanced Network Supervisory Controller (CAN/RS485 Smart Lithium Coordination)
The Huawei SMU11C is an advanced power system control unit designed for telecom rooms and data centers, serving as the central orchestration hub for rectifier modules, intelligent battery management, and environmental monitoring.
Talk to RICEWIND
Need to confirm a model, specification, or project configuration? Our team can follow up by email or phone.
Clear support from selection to delivery
360°Technical support
N+Service commitment
3Steps shipping
100%Customer satisfaction
- Control Architecture
- Multi-Sensor Collection & CAN Bus Coordination
- Battery Management
- Intelligent Lithium & Lead-Acid Management
- Communication Interfaces
- RS485 / CAN / Ethernet / Console
- Local Display
- LCD Screen & Keypad Operation
- Operating Temperature
- -40 ~ +75°C
- Form Factor
- 43.6 (1U) × 482 × 255 mm
What this product is
What this product is
Operating as the central processing unit (CPU) for power subracks, the SMU11C monitors and manages rectifiers, PDUs, and battery banks via CAN bus, featuring a built-in LCD and Web NMS interfaces.
What problem it solves
Effectively resolves legacy control limitations, inaccurate lithium battery management, lack of multi-channel environmental inputs, and sluggish remote NMS integration, greatly boosting reliability.
Who and where it is for
Widely deployed in Huawei embedded power systems, indoor telecom base station distribution cabinets, IDC data center rooms, and distributed energy station monitoring upgrades.
Core advantages
- High-Reliability Bus Coordination: High-speed CAN bus architecture enables precise current sharing and dynamic sleep scheduling for rectifiers.
- Intelligent Lithium Management: Advanced charge/discharge algorithms support SOH estimation, temperature compensation, and dual protection.
- Comprehensive Sensor Access: Integrates multi-channel dry contacts, temperature/humidity collection, and analog ports for environment monitoring.
- User-Friendly HMI & NMS: Equipped with intuitive LCD local control panel and remote Web/SNMP network management for easy maintenance.
Technical specifications
| Key specifications | Value |
|---|---|
| Control Architecture | Multi-Sensor Collection & CAN Bus Coordination |
| Battery Management | Intelligent Lithium & Lead-Acid Management |
| Communication Interfaces | RS485 / CAN / Ethernet / Console |
| Local Display | LCD Screen & Keypad Operation |
| Operating Temperature | -40 ~ +75°C |
| Form Factor | 43.6 (1U) × 482 × 255 mm |
| Overall System Efficiency | Up to 96.2% (Gold Standard) |
| Acoustic Noise | ≤ 55 dBA (at 25°C ambient load) |
| Ingress Protection Rating | IP20 (Indoor Dust & Finger Proof) |
| Dielectric Withstand Voltage | 3000VAC Input to Ground (< 5mA) |
Applications
01
Telecom 4G/5G macro cellular base stations and distributed remote power sites
02
Enterprise-grade cloud data center mission-critical -48V DC power distribution lineups
03
Utility power grid dispatch centers and high-voltage substation DC switchgear rooms
04
Railway transit signaling, automated train control, and communications equipment rooms
