Liebert GXT5 16kVA Official Product View 3
VertivModel: Liebert GXT5 16kVA

Vertiv Liebert GXT5 16kVA High-Capacity Rackmount Online UPS (16kVA/16kW 9U PF 1.0)

High-reliability online double-conversion high-frequency Uninterruptible Power Supply (UPS) delivering zero-millisecond pure sine wave power to critical IT loads.

Talk to RICEWIND

Need to confirm a model, specification, or project configuration? Our team can follow up by email or phone.

Request a quoteWhatsApp
Tel+86 17621197907

Clear support from selection to delivery

360°Technical support
N+Service commitment
3Steps shipping
100%Customer satisfaction
Apparent Power
16000 VA
Active Power
16000 W
Output Power Factor PF
1.0 (Ultra-High Power Factor)
AC Input Voltage
176 ~ 288 VAC (full-load single-phase/three-phase compatible)
Power Conversion Efficiency
95%
Form Factor
19-Inch Rackmount

What this product is

What this product is

High-reliability online double-conversion high-frequency Uninterruptible Power Supply (UPS) delivering zero-millisecond pure sine wave power to critical IT loads.

What problem it solves

Delivers large-scale rackmount backup power up to 16kW within standard 19-inch IT enclosures without requiring external floor-mounted cabinet units.

Who and where it is for

High-performance computing (HPC) server racks, enterprise IT rows, broadcast production hubs, and telecom core transmission racks.

Core advantages

  • True online double-conversion topology providing 0ms transfer time to isolate mains surges, sags, and harmonic distortions
  • High output power factor (PF up to 0.9-1.0) delivering maximum active power capacity for high-density IT server loads
  • Dual DSP digital processor control achieving over 95% operating efficiency and up to 99% in ECO mode
  • Intelligent battery management featuring automated boost/float switching and scheduled self-test routines

Technical specifications

Key specificationsValue
Apparent Power16000 VA
Active Power16000 W
Output Power Factor PF1.0 (Ultra-High Power Factor)
TopologyOnline double-conversion, high-frequency pure sine wave
AC Input Voltage176 ~ 288 VAC (full-load single-phase/three-phase compatible)
DC Output Voltage220/230/240 VAC (single-phase adjustable)
Power Conversion Efficiency 95%
Form Factor19-Inch Rackmount
Physical Dimensions430 × 400 × 750 mm (main unit + bypass module)
Operating Temperature Range0°C to +40°C

Applications

01

Enterprise and cloud data center core networking suites, server clusters, and SAN storage arrays

02

Financial banking transactions, securities clearing systems, and trading floor mission-critical IT

03

Healthcare medical imaging suites (MRI, CT scanners) and critical intensive care instrumentation

04

Industrial automation production lines, robotic workcells, and supervisory PLC control systems
